SERVO Products Puts The Industry Standard Power Feed To Work For You

  • Smoother Cuts
  • Longer Tool Life
  • Increased Productivity
  • Available for table, cross, or knee feeds

Get a smoother surface finish, higher accuracy and better repeatability. Reduce operator fatigue and increase your productivity, while you increase tool life. With SERVO Products' electronically controlled power feeds.

Servo

Now, your class 1 manual mill can deliver semi-automated machining with superior speed regulation, ramping and dynamic braking. Plus Servo Products' power feeds feature an integral safety clutch and circuit breaker for overload protection.

Call Dan Staehle at 414-315-3436 today to order!

Type 200 - Knee Feeds

  • Semi-automated machining on Class 1 mills up to 5 hp.
  • Peak torque (half-wave series motor): to 200 in-lb / 22.6 N*m torque
  • Intermittent torque: 150 in-lb / 17.0 N*m
  • Continuous torque: 120 in-lb / 13.0 N*m
  • Variable feed rate: 0-12 ipm / 0-305 mm/min. (knee).
  • Rapid traverse: 12 ipm / 305 mm/min. (knee).
  • Gear reduction ratio (motor to screw shaft): 72:1.
  • Helical gearing and torque limiting friction safety clutch with new and improved gear.
  • Electrical: 110V, 50/60 Hz, 4.0 Amps.
  • Approximate weight: 21 lb. / 9.4 kg.

Type 140 - Knee, Table, and Cross Feeds

  • Semi-automated machining on Class 1 mills to 3 hp.
  • Peak torque (half-wave series motor): to 140 in-lb / 15.8 N*m torque
  • Intermittent torque: 105 in-lb / 11.9 N*m
  • Continuous torque: 90 in-lb / 10.2 N*m
  • Variable feed rate: .75-25 ipm / 19-635 mm/min. (table and cross); 0-12 ipm / 0-305 mm/min. (knee).
  • Rapid traverse: 35 ipm / 889 mm/min. (table and cross); 12 ipm / 305 mm/min. (knee).
  • Gear reduction ratio (motor to screw shaft): 72:1.
  • Helical gearing and torque limiting friction safety clutch with new and improved gear.
  • Electrical: 110V, 50/60 Hz, 2.5 Amps.
  • Approximate weight: 15 lb. / 6.8 kg.

Type 150 - Table and Cross Feeds

  • Semi-automated machining on Class 1 mills to 3 hp
  • Peak torque (full-wave SCR control compound DC motor): to 150 in-lb / 17 N*m torque
  • Intermittent torque: 120 in-lb / 13.6 N*m
  • Continuous torque: 100 in-lb / 11.3 N*m
  • Variable feed rate: .50-35 ipm / 13-889 mm/min.
  • Rapid traverse: 35 ipm / 889 mm/min.
  • Gear reduction ratio (motor to screw shaft): 72:1
  • Smooth surface finish at speeds as low as 0.5 ipm or 13 mm/min. at full torque.
  • Superior speed regulation, ramping, dynamic braking, friction safety clutch and limiting circuit protection.
  • Helical gearing and torque limiting friction safety clutch with new and improved gear.
  • Electrical: 110V, 50/60 Hz, 3 Amps.
  • Approximate weight: 15 lb. / 6.8 kg.
